AMBOHR OXM-05L Oxygen Generator Portable Industrial Oxygen concentrator

Eat and drink healthy with this beautiful multi-purpose ozone purifier.

Description

Functions & Features.

• Simple structure, easy to operate, and stable oxygen output.
• Material: zeolite/alumina; each unit can work independently, and oxygen output can reach 3-10 LPM or higher.
• With a chiller for cooling air, no need for an additional refrigerant dryer for reducing cost.
• Oxygen purity can up to 90+5%. Two oxygen cylinders exchange working, auto drain water, nitrogen, and other impurities output.
• Parts with shipping: chiller, fan, and air inlet pipe.
• Oxygen outlet pressure: 0.06-0.08Mpa

AMBOHR OXM series oxygen concentrator 3L 5L 5LS 10LS 20LS 30LS

COMPREHENSIVE PROTECTION

AMBOHR ozone generator-your best health assistant!
Every one of us needs clean water, pure air, and non-toxic food, because only in this way can we live healthily and happily.

Specification & Packaging

Oxygen Output: 1-5L/min (5 LPM)

Air Inlet: 60-65L/min

Oxygen Concentration: 93±3%

Electrical: 110-120VAC, 220-240VAC 50/60Hz 330W

Output Pressure: 0.05MPa±10%

Noise: 49dB

Oxygen Dewpoint: -4ºF (-20ºC)

Operational temperature: 32ºF to 105ºF (0ºC to 40ºC.), R.H.≤85%

Advice temperature: 41ºF to 77ºF (5ºC to 25ºC.), R.H.≤30%~60%

Expected Life: 10000H

Alarms: Power failure, temperature, over current

Isolation Mounts: Included & installed

Circuit Dimension(LxWxH): 18.1”*9.1”*10.3”(460*230*262mm)

Dimension(LxW): 13.5”*8.4”(345*213mm)

Net Weight: 26 lb (12 kg)

Product Application

Customers make demands, we say OK

We are a professional module manufacturer and have served oxygen generator suppliers in various industries. We can make the most perfect solution for customers according to customer application scenarios.
